UNIVERSAL COILOVER & LONG TRAVEL SHOCK ABSORBERS
Elevate your off-road experience with Dobinsons superior suspension technology.
Introducing Dobinsons Spring & Suspension’s new High Performance UNIVERSAL COILOVER & LONG TRAVEL SHOCK ABSORBER. Tailored for custom and long travel suspension setups - these products offer ADVANCED ADJUSTABILITY in compression and rebound.
NEW

THIS NEW RANGE OF 2.5” ADJUSTABLE REMOTE RESERVOIR DUAL RATE COILOVERS & LONG TRAVEL SHOCK ABSORBERS HAVE BEEN DESIGNED AND MANUFACTURED WITH THE HIGHEST LEVEL OF PERFORMANCE AND RELIABILITY IN MIND. MANUFACTURED FROM HIGH STRENGTH DOM 3MM WALL STEEL TUBING, DOBINSONS COILOVERS/SHOCKS UTILISE A 2.6”/66MM BODY, WITH A 2.35”/60MM HIGH-FLOW CNC MACHINED T6 6061 PISTON, DESIGNED TO BE FITTED WITH 3” INSIDE DIAMETER COIL SPRINGS.
HIGH SPEED COMPRESSION ADJUSTMENT
LOW SPEED COMPRESSION ADJUSTMENT
REBOUND ADJUSTMENT
HIGH SPEED
COMPRESSION


High speed compression primarily affects the compression damping during high speed shaft movements such as harsh or square edge bumps and harsh vehicle landings.
LOW SPEED
COMPRESSION


Low speed compression primarily affects the compression damping during low speed shaft movements such as vehicle pitch, dive and roll, wheel traction and vehicle ride (harshness and plushness).
REBOUND
DAMPING


Rebound damping primarily affects vehicle traction, damper top-out and vehicle body movements such as vehicle pitch, dive and roll.

LOWER LEG
Single Piece Lower Leg*
REMOTE RESERVOIR
60mm 6063 Aluminium Remote Reservoir
HIGH STRENGTH SHOCK SHAFT
5140 HV900 Hard Chrome Plated, Heat treated 18 / 22mm Micro-Polished high strength Shock Shaft with a minimum tensile strength exceeding 700MPA
HIGH PRESSURE HOSES
Parker™ Braided High Pressure Hoses
ADJUSTABLE SPRING SEAT
T6 6061 Height Adjustable Spring Seat*
HEAVY DUTY BODY
3mm Thick Heavy Duty DOM Seamless 56mm / 66mm O.D. shock Body Precision Honed to +/- 0.04mm

REBUILDABLE

CNC MACHINED COMPONENTS

3 STAGE SEALING SYSTEM

HIGH FLOW PISTON

FLOATING PISTON

COMPOSITE WEAR BAND






Specifications
COIL-OVER SHOCK ABSORBERS
Part Number | Extended inch/mm) | Compressed (inch/mm) | Reservoir Length (inch/mm) | Travel Length (inch/mm) | Hose Length (inch/mm) | Rod Diameter (mm) |
---|---|---|---|---|---|---|
MRA92-A2510 |
29.45/750 |
19.48/496 |
10/250 |
10/250 |
19.6/500 |
22 |
MRA92-A2512 |
33.42/851 |
21.48/547 |
12/300 |
12/300 |
19.6/500 |
22 |
MRA92-A2514 |
38.49/980 |
24.00/611 |
12/300 |
14/350 |
19.6/500 |
22 |
LONG TRAVEL SHOCK ABSORBERS
Part Number | Extended inch/mm) | Compressed (inch/mm) | Reservoir Length (inch/mm) | Travel Length (inch/mm) | Hose Length (inch/mm) | Rod Diameter (mm) |
---|---|---|---|---|---|---|
MRA92-A2520 |
28.4/722 |
19.48/496 |
10/250 |
10/250 |
19.6/500 |
22 |
MRA92-A2522 |
32.4/824 |
20.5/522 |
12/300 |
12/300 |
19.6/500 |
22 |
MRA92-A2524 |
37.3/948 |
24.00/611 |
12/300 |
14/350 |
19.6/500 |
22 |
