Suitable For

A vehicle image representing the page's contents

Type:

Patrol, Safari

Model:

Y60 GQ (1987 to 1998), Y61 GU (1997 on)

Variant:

LWB Wagon & Pickup / Utility (3" Lift)

Detail:

Wagon & Pickup / Utility,
75mm (3” Lift)

Download Catalogue Page

WARNING - 75MM (3”) OR HIGHER LIFT

The suspension components listed on this page are for off-road use only.

•Refer to Local Laws before Fitting to Registered/Road Vehicles

•An Engineering Certificate may be required

•Handling Characteristics will Diminish on Lifts Above 50mm (2”)

The following modifications (but not limited to) need to be made to the vehicle before the kit is fitted.

•Adjustable Panhard Rods

•Modified Leading / Trailing Arms

•Brake Hoses

•Extended Bump Stops

•Gear Box & Drive Line Modifications

•Steering Arms

•Swaybar Modification

Dobinsons Spring & Suspension do not accept any responsibility for injury caused to person or property through the use of the products listed on this page.

These products do not come with any warranty or guarantee.

Coil Springs: Sold in Pairs. Torsion Bars: Sold in Pairs. Prices are subject to change without notice. *Raised Height Measurements are Listed as a Guide Only

Front

Coil Spring

4.5L Petrol, 2.8L & 3.0L T/Diesel, 4.2L Diesel

Linear Rate

Part Number

C45-134

Availability

Linear Rate
50-100Kg

Part Number

C45-308

Availability

4.8L Petrol, 4.2L T/Diesel

Linear Rate
Up to 40Kg Accessories

Part Number

C45-308

Availability

Linear Rate
50-80Kg

Part Number

C45-310

Availability

Linear Rate
Extra Heavy Duty
80-100Kg

Part Number

C45-108

Availability

Shock Absorber

Twin Tube Nitro-Gas

Part Number

GS51-116

Availability

IFP Monotube Shock (IMS)

Part Number

IMS51-60116

Availability

Monotube Remote Reservoir
(3-Way Adjustable)

Part Number

MRA51-A116

Availability

Shock Absorber Reservoir Mounting

Reservoir Mounting Bracket Kit

Part Number

RM45-007

Availability

Recommended For Optimal Remote Reservoir Fitment, Positioning & Strength

Steering Damper

Heavy Duty (Big Bore) - Complete with Fittings

Y60 GQ
1988 to 08/1989 (Wagon)

Part Number

SD45-834

Availability

Y60 GQ
08/1989 to 1999
(Wagon & Pickup)

Part Number

SD45-836

Availability

Y61 GU
12/1997 to 02/2000 (Wagon)

Part Number

SD51-811

Availability

Y60 GQ & Y61 GU
01/1999 on (Pickup)

Part Number

SD51-811

Availability

Y61 GU
02/2000 on (Wagon)

Part Number

SD45-801

Availability

Some 02/2000 on Latin American Wagons May Require SD51-811.
Check End Configuration Before Ordering.

Adjustable Monotube Heavy Duty - Complete with Fittings & Mounts

Y60 GQ & Y61 GU
Suits Draglinks and Panhard Rods 28-38mm Ø
May Require Existing Mounts To Be Cut Off

Part Number

SS51A811

Availability

Bump Stop

Hydraulic Bump Stop

Hydraulic Bump Stop
Threaded Height Adjustable
66mm Body x 57mm Travel
(2"-4" Lift)

Part Number

HBS66-002

Availability

Hydraulic Bump Stop
Threaded Height Adjustable
66mm Body x 85mm Travel
(4"-6" Lift)

Part Number

HBS66-003

Availability

Hydraulic Bump Stop Mounting

Hydraulic Bump Stop Mounting Kit
(Weld In)
(Excludes Bump Stops)

Part Number

HBS45-007K

Availability

Rubber Bump Stop

Adjustable Soft-Hit Bump Stop
(Suits 0-56mm extension)

Part Number

BS45-528

Availability

Castor Kit

Raising Vehicle Will Effect Castor Angle. A Wheel Alignment is Recommended to Determine if a Castor Kit is Required.

Adjustable Front Radius Arm Castor Kit
Angle Settings: ±0°, ±2.5° or ±3.5°
4 x Polyurethane Eccentric Bushes

Part Number

PB59-503K

Availability

Icon for a Dobinsons Offset Radius Arm Bush

Fixed Rubber Front Radius Arm Castor Kit
Angle Setting: ±2.5°
4 x Rubber Eccentric Bushes

Part Number

RB59-522K

Availability

Radius Arm Bush

0 Degree Standard Radius Arm Bush Kit
Arm to Diff
4 x Rubber Bushes

Part Number

RB59-536K

Availability

Arm to Chassis Bush Kit
4 x Rubber Bushes

Part Number

RB45-535K

Availability

Drop Box Kit

5° Drop Box Kit (Sold as a Pair)
1 x Left Hand & 1 x Right Hand

Part Number

WA45-509K

Availability

May be Required for Vehicles Lifted Closer to 4”.
Extensive Modifications Are No Longer Required to Fit This Kit.
Gives a 5° of Castor Adjustment.
Leading Arm Modifications are not Required when Fitting this Part Number.

Castor Plate Kit

5° Castor Plate Kit (Suits Both Arms)

Part Number

WA45-513K

Availability

Panhard Rod

Suits Y60 GQ & Y61 GU - Complete with Bushes

Adjustable Panhard Rod
Right Hand Drive
to 02/2000 (Wagon)

Part Number

PR45-1402

Availability

Adjustable Panhard Rod
Right Hand Drive
1992 on (Pickup)

Part Number

PR45-1402

Availability

Adjustable Panhard Rod
Left Hand Drive
to 02/2000 (Wagon)

Part Number

PR45-1407

Availability

Adjustable Panhard Rod
Left Hand Drive
1992 on (Pickup)

Part Number

PR45-1407

Availability

Suits Y61 GU Only - Complete with Ball Joint & Bush

Adjustable Panhard Rod
Right Hand Drive
02/2000 on (Wagon)

Part Number

PR45-1416

Availability

Adjustable Panhard Rod
Left Hand Drive
02/2000 on (Wagon)

Part Number

PR45-1409

Availability

Panhard Rod Bush

Does Not Fit OE
Upper/Chassis Bush

Part Number

RB45-6025

Availability

Does Not Fit OE
Lower/Diff Bush

Part Number

RB45-6027

Availability

Does Not Fit OE
Ball Joint-Upper/Chassis Bush

Part Number

BJ45-6026

Availability

Draglink

Suits GQ/Y60

38mm Solid Adjustable

Part Number

SA45-1422

Availability

Spare Rod Ends To Suit SA45-1422

Part Number

SA45-022RE

Availability

Suits GU/Y61

38mm Solid Adjustable

Part Number

SA45-1424

Availability

Spare Rod Ends To Suit SA45-1424

Part Number

SA45-024RE

Availability

Gearbox Spacer Kit

Recommended For Reducing Drive Line Vibration On Raised Vehicles

Part Number

TC45-001K

Availability

Sway Bar Extension

Adjustable Sway Bar Extension
(Suits 4" to 6" Lift)

Part Number

SE45-520

Availability

Rubber Coil Seat

Replacement Upper Rubber Coil Seat

Part Number

RS45-4026

Availability

Rear

Coil Spring

GQ - GU Series I, II, III, IV

Linear Rate
No Load, Extra Light
(Pick-ups Only)

Part Number

C45-189

Availability

Linear Rate
No Load

Part Number

C45-129

Availability

Linear Rate
50-100Kg Constant Load

Part Number

C45-329

Availability

Linear Rate
100-250Kg Constant Load

Part Number

C45-309T

Availability

Linear Rate
250-350Kg Constant Load

Part Number

C45-325T

Availability

Linear Rate
Raised Height (45mm Lift)
500-600Kg Constant Load

Part Number

C45-313T

Availability

Tower Bracing Recommended

Linear Rate
Raised Height (45mm Lift)
550-700Kg Constant Load

Part Number

C45-315T

Availability

Tower Bracing Recommended

Linear Rate
Raised Height (45mm Lift)
750-850Kg Constant Load

Part Number

C45-335T

Availability

Tower Bracing Recommended

GU Series V

Linear Rate
No Load, Extra Light
(Pick-ups Only)

Part Number

C45-189

Availability

Linear Rate
No Load

Part Number

C45-329

Availability

Linear Rate
50-150Kg Constant Load

Part Number

C45-309T

Availability

Linear Rate
200-300Kg Constant Load

Part Number

C45-325T

Availability

Linear Rate
Raised Height (45mm Lift)
450-550Kg Constant Load

Part Number

C45-313T

Availability

Tower Bracing Recommended

Linear Rate
Raised Height (45mm Lift)
500-650Kg Constant Load

Part Number

C45-315T

Availability

Tower Bracing Recommended

Linear Rate
Raised Height (45mm Lift)
700-800Kg Constant Load

Part Number

C45-335T

Availability

Tower Bracing Recommended

Shock Absorber

Twin Tube Nitro-Gas

Part Number

GS45-913

Availability

IFP Monotube Shock (IMS)

Part Number

IMS45-60913

Availability

Monotube Remote Reservoir
(3-Way Adjustable)

Part Number

MRA45-A913N

Availability

Includes Reservoir Mounts (RM45-017) To Suit Genuine Rear Fuel Tanks Only

Universal Reservoir Mount Bracket (RM80-005) May Be Required If Standard Mounts Do Not Work (Sold Separately)

Bump Stop

Hydraulic Bump Stop

Hydraulic Bump Stop
Threaded Height Adjustable
56mm Body x 50mm Travel
(3"-6" Lift)

Part Number

HBS56-001

Availability

Hydraulic Bump Stop Mounting

Hydraulic Bump Stop Mounting Kit
(Bolt In)
(Excludes Bump Stops)

Part Number

HBS45-008FK

Availability

Rubber Bump Stop

Adjustable Soft-Hit Bump Stop
(Suits 0-56mm extension)

Part Number

BS45-529

Availability

Control Arm

Upper Control Arm

Adjustable Upper Control Arms (Pair)
with Bushes

Part Number

WA45-510K

Availability

Lower Control Arm

Adjustable Lower Control Arms (Pair)
40mm OD
6mm Wall

Part Number

WA59-551K

Availability

Brake Adjuster

Recommended when Raising Vehicle
(Suits 2" to 6" Lift)

Part Number

BA45-005

Availability

Panhard Rod

Suits Y60 GQ & Y61 GU

Adjustable Panhard Rod
Complete with Bushes
to 02/2000 (Wagon)

Part Number

PR45-1403

Availability

Adjustable Panhard Rod
Complete with Bushes
1992 on (Pickup)

Part Number

PR45-1403

Availability

Suits Y61 GU Only (Ball Joint to Chassis Mount)

Adjustable Panhard Rod
Complete with Ball Joint and Bush
02/2000 on (Wagon)

Part Number

PR45-1415

Availability

Panhard Rod Bush

Does Not Fit OE
Upper/Chassis Bush

Part Number

RB45-6025

Availability

Does Not Fit OE
Lower/Diff Bush

Part Number

RB45-6027

Availability

Does Not Fit OE
Ball Joint-Upper/Chassis Bush

Part Number

BJ45-6026

Availability

Sway Bar Extension

* Check Sway Bar Link Configuration - Some Vehicles Require 2 of the Same Sway Bar and Other Vehicles Require 1 of Each Sway Bar

Adjustable Sway Bar Extension
(Suits 4" to 6" Lift)
Stem Upper/Right Angle Lower Joint*

Part Number

SE45-520

Availability

Adjustable Sway Bar Extension
(Suits 4" to 6" Lift)
Right Angle Upper/Right Angle Lower Joint*

Part Number

SE45-521

Availability

Rubber Coil Seat

Replacement Upper Rubber Coil Seat

Part Number

RS45-4027

Availability

Under Body Bush Kit

Kit Includes Front & Rear Under Body Bushes
*Excludes Spherical Panhard Rod Bush for Wagon Models 02/2000 on

Post 1989
Kit Contains:
4 x Front Radius Arm to Chassis Bush
4 x Front Radius Arm to Diff Bush
4 x Front & Rear Panhard Rod Bush
8 x Rear Upper & Lower Control Arm Bush

Part Number

PB45-1239K

Availability
