Suitable For

Type:

D90

Model:

SV9A (2017 on)

Variant:

Detail:

4x4

Download Catalogue Page

Coil Springs: Sold in Pairs. Torsion Bars: Sold in Pairs. Prices are subject to change without notice. *Raised Height Measurements are Listed as a Guide Only

Front

Coil Spring

Linear Rate
Raised Height (20mm Lift)

Part Number

C59-134

Linear Rate
Raised Height (45mm Lift)

Part Number

C59-296

Linear Rate
Raised Height (45mm Lift)
50-100Kg

Part Number

C59-300

3" Lift - Requires IMS21-50472, DD21-590K & WA21-546K

Linear Rate
Raised Height (75mm Lift)

Part Number

C59-302

Linear Rate
Raised Height (75mm Lift)
50-100Kg

Part Number

C59-314

Shock Absorber

IFP Monotube Shock (IMS)
Adjustable Spring Seat Height
X = 195mm / 7.48”

Part Number

IMS21-50470

X - Centre of Eye to Spring Seat

Suitable Only For 75mm Lift
Requires DD21-590K & WA21-546K

IFP Monotube Shock (IMS)
Adjustable Spring Seat Height
X = 195mm / 7.48”

Part Number

IMS21-50472

X - Centre of Eye to Spring Seat

Bump Stop

Rubber Bump Stop

Replacement Bump Stop
Progressive Adjustable 0-20mm Extension

Part Number

BS59-560

Replaces Original Bump Stop.
If Exceeding Listed Spring Seat Heights This MUST Be Used To Prevent Coil Bind.

Strut Top Cap

Part Number

SC59-002

Diff Drop Kit

Part Number

DD21-590K

Decreases CV Angle

DD21-590K Must Not Be Fitted Without UCA Ball Joint Spacer WA21-546K

Ball Joint Spacer

UCA Ball Joint Spacer

Part Number

WA21-546K

UCA Ball Joint Spacer WA21-546K Must Not Be Fitted Without DD21-590K

Rear

Coil Spring

Variable Rate
Standard Height
200-300Kg Constant Load

Part Number

C21-415V

Variable Rate
Raised Height (45mm Lift)

Part Number

C21-415V

Variable Rate
Raised Height (45mm Lift)
100-200Kg Constant Load

Part Number

C21-417V

Shock Absorber

IFP Monotube Shock (IMS)

Part Number

IMS45-50646B
