Suitable For

A vehicle image representing the page's contents

Type:

Ram

Model:

1500 (2009 to 2021)

Variant:

DS - 2"-3" Lift (Eye/Eye Rear Shock)

Detail:

4x4, 2"-3" Lift
Eye Bush Top & Bottom Rear Shock Absorber - Confirm Before Ordering

Download Catalogue Page

Coil Springs: Sold in Pairs. Torsion Bars: Sold in Pairs. Prices are subject to change without notice. *Raised Height Measurements are Listed as a Guide Only

Front

Coil Spring

Must Fit Upper Control Arms When Fitting Coil Springs

Linear Rate
Raised Height (50mm Lift)
0-40Kg

Part Number

C16-038

Availability

Linear Rate
Raised Height (50mm Lift)
Heavy Duty
100-200Kg

Part Number

C16-044

Availability

Shock Absorber

Must Fit Upper Control Arms When Fitting Shock Absorbers

IFP Monotube Shock (IMS)
Adjustable Spring Seat Height
X = 184mm / 7.22"

Part Number

IMS16-60302

Availability

X - Centre of Eye to Spring Seat

NOTE: For 3" Lift - Front Set X = 197mm / 7.73"

Monotube Remote Reservoir
(3-Way Adjustable)
Assembled Coil Over
Includes C92-3013600,
13" x 600lbs/in Coil Spring
Suits 2"-3" Lift, 0-100kg
Pre-load -
2” – 0kg = 84mm
2” – 70-100kg = 96mm
3” – 0kg = 94mm
3” – 70-100kg = 106mm

Part Number

MRA16-A302

Availability

Control Arm

Upper Control Arm

(Pair) 3º Castor Built In
Rubber Bushes
with Ball Joint

Part Number

UCA16-008K

Availability

Rear

Coil Spring

Variable Rate
Standard Height
Heavy Duty
400-600Kg Constant Load

Part Number

C16-039V

Availability

Variable Rate
Raised Height (50mm Lift)
Suitable For Towing - Light Unloaded & Firmer When Towing

Part Number

C16-039V

Availability

Linear Rate
Raised Height (50mm Lift)
Heavy Duty
Up to 50Kg Constant Load

Part Number

C16-037

Availability

Linear Rate
Raised Height (50mm Lift)
Heavy Duty
500Kg Constant Load

Part Number

C16-041

Availability

Shock Absorber

IFP Monotube Shock (IMS)

Part Number

IMS45-60913

Availability

Monotube Remote Reservoir
(3-Way Adjustable)

Part Number

MRA45-A913

Availability
